Reading Radar Right

One of the most misunderstood pieces of equipment in the modern cockpit is airborne weather radar. For most of us, its a luxury we cant afford: either sferic devices (Stormscope/Strikefinder) and/or datalinked Nexrad images serve as a pilots third-best tool for avoiding thunderstorms. We say "third-best" because the best thing ever used for this purpose remains the Mk. I, Mod. I human eyeball. The trick, of course, is the eyeball only can be used in visual conditions. By happy coincidence, thats the best place to be when contemplating flight in an area of thunderstorms. But visual circumnavigation of convective activity isnt always possible. Instead-and if youve got the room in the nose or a wing-mounted radome-an airborne radar installation remains your second-best solution. Yes, Nexrad is widely available and much less expensive, but it doesnt do the same job as the airborne equipment.

Key Takeaways:

• Airborne weather radar is a crucial tool for tactical thunderstorm avoidance, but it cannot directly detect all hazards like turbulence, icing, hail, or lightning, instead inferring them from liquid water presence.
• Pilots must understand radar display interpretations (e.g., color intensity indicating hazard levels) and be aware of critical limitations such as "attenuation," where dense precipitation can block signals and hide dangerous weather behind it.
• The proper and safe use of airborne weather radar is complex and requires specialized training to accurately interpret its output and understand its capabilities, as well as its inherent limitations.
