VORs in the G1000

Fred Simonds

Tuesday, February 23, 2021 at 11:34 AM ET

Verified

Key Takeaways:

Pilots often underutilize the Garmin G1000's robust VOR capabilities, despite their critical importance for IFR navigation, regulatory compliance (especially for non-WAAS units), and as a primary backup like the VOR-based Minimum Operational Network (MON) during GPS outages.
Maintaining proficiency in VOR navigation is essential for G1000 pilots, who can effectively use the system's CDI and bearing pointers to tune, identify, and track VORs for primary navigation or cross-referencing, even when GPS is unavailable.
The article demonstrates practical G1000 VOR navigation through a simulated GPS failure, highlighting step-by-step procedures for using VOR functions to navigate en route, identify fixes with bearing pointers, and execute ILS approaches to a MON airport.

See a mistake? Contact us.

Garmin has sold over 16,000 Garmin G1000 units since its introduction in 2003. Properly used, a G1000 can make you look mighty good trekking the skies under IFR. Pilots gravitate to its feature-rich GPS capabilities. Yet too many pilots shortchange themselves if they neglect the machine’s considerable VOR resources.

If your G1000 lacks WAAS, then its use under IFR requires an alternate approved and operational means of navigating the proposed flight route, per AIM 1-1- 17.2.a.2. Practically speaking this means VOR. If your G1000 is WAAScapable, it requires no other radio navigation equipment. Unsure? Go to the AUX MFD page and press the SBAS button. The unit is WAAS-equipped if WAAS is checked.
