Beech 95B-55 Baron Corroded Fuel Pressure Line Out of concerns about chafing or corrosion, a technician was motivated to closely inspect the right fuel-flow pressure gauge line where it crosses the defrost duct. He was right, finding extensive corrosion at the point of contact. After the line was removed, slight bending pressure cracked the area wide open and it was seen that 288 the corrosion had actually penetrated to the inside of the line, yet the line was not leaking. If a leak started, the only way to stop it would be to shut down the right engine. Part Total Time: 3000 hours Cessna 182R Failed Fuel Injection Intake Tube Shortly after a normal flight, engine restart could not be accomplished. The rubber tube connecting the intake manifold to the fuel induction rail was found to be fully separated at the manifold, causing a large vacuum leak downstream of the carburetor and rendering the engine inoperable. The failed connection was between the Y-shaped intake manifold and the fuel rail on the right side. Part Total Time: 262 hours. Cessna 441 Failed Hydraulic Line Three Cessna 400 series aircraft operated by the same company sustained hydraulic system failures. Two involved the wingflap system and the third the landing gear. The cracks formed at bends just barely meeting industry minimum recommended radii for 3/8-inch alloy tubing and formed at what appears to be minor tool die marks or stressed areas in the bend radii. The submitter recommends in- creased inspections-including paint removal at any bend radii-for tooling die and stress marks. Any line appearing under the minimum bend radius (standard) should be replaced. Part Total Time: Various Rotax 912ULS Failed Crankshaft Connecting Rod The number-three crankshaft rod failed in flight, knocking a hole in the crankcase. The engine remained running and the pilot was able to return to the airport. One quart of oil remained in the oil tank. A tear-down inspection was performed but was unable to determine a conclusive cause for this engine failure (p/n 888164). Part Total Time: 607 hours Slick 4330 Magneto Broken Impulse Coupling The l/h magneto on the r/h engine cut out while running the engine. After removing the magneto, the impulse coupling hub spacer was found to have pulled away from the rivets and split into two pieces. Part Total Time: 977.0 hours
Chafed, Corroded, Failed
Out of concerns about chafing or corrosion, a technician was motivated to closely inspect the right fuel-flow pressure gauge line where it crosses the defrost duct. He was right, finding extensive corrosion at the point of contact. After the line was removed, slight bending pressure cracked the area wide open and it was seen that the corrosion had actually penetrated to the inside of the line, yet the line was not leaking. If a leak started, the only way to stop it would be to shut down the right engine.
Key Takeaways:
- Aircraft components, including fuel lines, intake tubes, hydraulic lines, and engine accessories, are prone to various failures stemming from hidden corrosion, material fatigue at stress points, or part separation.
- Thorough and proactive inspections are crucial to identify potential issues, such as deeply corroded lines or cracks at minimum bend radii, before they escalate into active leaks or system malfunctions.
- Incidents like a failed crankshaft connecting rod highlight that even significant engine component failures may not immediately lead to full engine loss, potentially allowing for safe flight termination.
